DFA127  Overhead swing drive unit.

Suitable for many public areas but chiefly for applications inside buildings, as follows:
To provide helpful solutions for the disabled in blocks of flats, hospitals and homes for the elderly
For administration and office buildings
For public transport buildings
For restaurants and hotels

Uses and benefits
The Record swinging door operator features refined technology, compact design and practically silent operation. The DFA 127 is Record’s first swing door operator that can be used as the basis for a wide variety of swing door applications


Can be used as automatic door control system to provide fire and smoke protection
Extendable with master-slave function (two overlapping door leaves)
Available in both FULL POWER or LOW ENERGY models
Operator also available as INVERS, FIRE and in-ground models



Technical Data


Dimensions of operator L x H x D

600 x 85 x 124 mm

Weight of operator max.

approx. 12 kg

Door closer range

Covers the EN 4 to EN 6 range for standard and sliding arm

Operating opening speed Operating closing speed

3 – 20 s 5 – 20 s

Opening angle

70 – 115°

Electrical connections

230 V / 50/60 Hz

Linkage Assembly option Operator housing

- Standard arm pushing - Sliding arm pulling DIN left / right for lintel assembly (lintel up to 330 mm for standard arm only) stainless steel

DFA127 Slide Arm

DFA127 Slide Arm

£153.00 Inc VAT £183.60

DFA127 Push Arm

DFA127 Push Arm

£148.00 Inc VAT £177.60

DFA127 Lever Adaptor

DFA127 Lever Adaptor

£30.00 Inc VAT £36.00

Record BDE-D Control Unit

Record BDE-D Control Unit

£105.00 £130.00 Inc VAT £126.00

Record Floor Guide

Record Floor Guide

£58.65 Inc VAT £70.38

Record STA16/17 Carriage

Record STA16/17 Carriage

£96.00 Inc VAT £115.20

Write a review

Please login or register to review

DFA127 Swing Door Operator

  • Brand: Record
  • Product Code: DFA127
  • Availability: In Stock
  • £899.10

  • Inc VAT £1,078.92
