This product is currently out of stock. You can still place an order for the item, we will immediatly source the item and dispatch it as soon as we receive it.


Activate your Automatic Door in Style with this Versatile Uni-Directional Microwave Sensor
Ideal for automatic sliding or swing doors where a large detection area is required at mounting heights of up to 4m

  • Large Detection Area

Perfect for use on garden centres, DIY stores, or any door that is approached at speed with a shopping trolley

  • Swing Door Activation

Advanced cross traffic filtering technoloy makes the Domino 1000 the ideal solution for the swing side activation of swing doors

  • Reduced Building Energy Loss

Reduce door-open time through the unidirectional detection and cross traffic filtering functions of the Domino 1000

  • High Installation Height

Mount at heights of up to 4m

Technical Specifications:

Model  Domino1000 Pedestrian Door Activation
Detection Method  K-Band 24.05Ghz - Microwave Motion Detection
Installation Height  Max 4000mm (13ft)
Sensor Dimensions  123mm (W), 65mm (H), 57mm (D)
Pattern Adjustment  Width Adjustment: Antenna adjustment left/right up to 3 steps
  Width Adjustment: Sensitivity Adjustment (Potentiometer)
  Depth Adjustment: Antenna adjustment up/down 0° - 40° in 5° steps
  Depth Adjustment: Sensitivity Adjustment (Potentiometer)
Presence Timer  None
IP Rating  54
Power Supply  12 to 36V DC or 12 to 28V AC
Current Consumption  50mA @ 24V DC, 20°C
Power  < 1W
Transmitting Power  < 20 dBm
Relay Output Floating  NO or NC
Relay Hold Time  0.2sec - 4 sec (Factory setting 1 sec)
Nominal Power  0.5A 120V AC / 1A 24V DC
Max. Switching Power  24W/60VA
Max. Switching Voltage  48V AC / 48V DC
Max. Switching Current  1A
Min. Detection Speed  0.1 m/s
LED Indication  Power On = Green
  Detecting = Red
  Command Received = Green Flashing
  Error = Red Flashing
  Initialisation after power on = Green/Red Flashing
Operating Temperature  -20°C to +60°C, (-4°F to 140°F)
Weight  120g (0.26 lbs)
Available Colours  Black: Product Code = Domino1000
Accessories Provided  Connection Cable
  Mounting Template
  Mounting Screws

Installation Instructions

Download Domino 1000 Brochure: Domino1000.pdf

Download Domino 1000 Installation Instuctions: Domino1000 Installation Instructions.pdf
